Galvo & fiber
Galvo marking, finally without the headache
Fiber, MOPA, UV or CO2 galvo: Bernie prepares, simulates and exports your markings, from the lens field all the way to the rotary.
In detail
Galvo device
- Lens field The workspace, with offset, rotation and mirroring.
- Sources Fiber, MOPA, UV, CO2, SPI — and a second source.
- Lens corrections Bulge, skew, trapezoid, calibration with a 9-cross pattern.
- Jumps and delays Finely adjustable, layer by layer.
Marking
- Virtual galvo Duration, marked length, jumps and points outside the field, before a single shot.
- Live framing The red frame follows the selection as you move it with the keyboard.
- Series Parts counted, repeat, stop at the counter, automatic rotation from one part to the next.
Objects and axes
- Cylinder correction For objects laid flat, convex or concave.
- Galvo rotary Marking in slices, on rollers or a chuck.
- External axis Linear stage or turntable: split or repeated marking.
EZCad
- .ezd projects Import (pens, hatches, images, texts) and export checked in EZCad 2.14.11.
- Configuration Import of markcfg (EZCad2) and Motors.ini (EZCad3).
Explore the other features
- Drawing & text A vector editor built for the laser
- Images & photos Photos that engrave as well as they look on screen
- Layers & materials Every colour, a setting. Every material, its recipe.
- Preview & safety Nothing goes to the laser without being checked
- Connection & control Your laser connected and under control in seconds
- Camera & rotary Engrave exactly where you planned to
- Files & automation Your files come with you. So do your habits.
All this, for €0.
Every feature on this page is included, on every platform, for everyone.
